HHBB Type Electric Chain Hoist
SY is a large-scale HHBB Type Electric Chain Hoist manufacturer and supplier in China.We have been specialized in hoisting machinery for many years.As a factory,the price advantage, OEM&ODM capability,strict quality control system and good sales-after service bring us so many clients all over the world.We look forward to becoming your long-term partner in China.
Send Inquiry
Product Description
The HHBB Type Electric Chain Hoist is an electric lifting equipment that is designed to lift and transport heavy loads in industrial settings. It is a popular choice due to its high lifting capacity, efficient operation, and user-friendly controls. The electric chain hoist is ideal for use in a variety of industrial settings, including factories, warehouses, and other material-handling environments. It is easy to install, operate and maintain and can save significant amounts of time, effort, and labor costs that would be required by a manual chain hoist.
HHBB Series Electric Chain Hoist include hook type electric hoist, running type electric hoist,and low headroom type electric hoist. Every type could be equipped to single speed and double speed.
Features:
• Operating voltage is 24V/36V, safety to workers;
• Dual break system, immediately performed by automatic brake during emergency power cut;
• Limit switches to protect both lifting and dropping works to prevent from exceeding the limits;
• Special anti phase power protective device to control over failure circuit of wrong power connection.
• Hand switch us 4 push direction buttons with emergency button too.
• G80 galvanized or blacking lifting chain, high tensile alloy steel with heat treatment.
• Power 220V-660V, 50Hz/60Hz, 3 Phase; Dual voltage available.
SY HHBB Series Electric Chain Hoist(Fixed Type) Parameter
|
Model |
Capacity (Ton) |
Lifting Height (m) |
Lifting Speed (m/min) |
Lifting motor |
||||
|
Power (KW) |
Rotation Speed (R/min) |
Phases |
Voltage (V) |
Frequency (Hz) |
||||
|
0.5 |
3/9 |
7.2 |
1.1 |
1440 |
3 |
380 |
50 |
|
|
1 |
3/9 |
6.8 |
1.5 |
1440 |
3 |
380 |
50 |
|
|
1 |
3/9 |
3.6 |
1.1 |
1440 |
3 |
380 |
50 |
|
|
1.5 |
3/9 |
8.8 |
3.0 |
1440 |
3 |
380 |
50 |
|
|
2 |
3/9 |
6.6 |
3.0 |
1440 |
3 |
380 |
50 |
|
|
HHBB02-02 |
2 |
3/9 |
3.4 |
1.5 |
1440 |
3 |
380 |
50 |
|
HHBB2.5-01 |
2.5 |
3/9 |
5.4 |
3.0 |
1440 |
3 |
380 |
50 |
|
HHBB03-01 |
3 |
3/9 |
5.4 |
3.0 |
1440 |
3 |
380 |
50 |
|
3 |
3/9 |
4.4 |
3.0 |
1440 |
3 |
380 |
50 |
|
|
HHBB03-03 |
3 |
3/9 |
2.2 |
1.5 |
1440 |
3 |
380 |
50 |
|
HHBB05-02 |
5 |
3/9 |
2.7 |
3.0 |
1440 |
3 |
380 |
50 |
|
HHBB7.5-03 |
7.5 |
3/9 |
1.8 |
3.0 |
1440 |
3 |
380 |
50 |
SY HHBB Series Electric Chain Hoist(Running Type) Parameter
|
Model |
Capacity (Ton) |
Lifting Height (m) |
Lifting Speed (m/min) |
Lifting motor |
Operating motor |
||||||||||
|
Power (KW) |
Rotation Speed (R/min) |
Phases |
Voltage (V) |
Frequency (Hz) |
Power (KW) |
Rotation Speed (R/min) |
Operating speed(m/min) |
Phases |
Voltage (V) |
Frequency (Hz) |
I-Beam(mm) |
||||
|
HHBB0.3-01 |
0.3 |
3/9 |
7.1 |
0.4 |
1440 |
3 |
380 |
50 |
0.12 |
1440 |
12.2 |
3 |
380 |
50 |
58-153 |
|
HHBB0.5-01 |
0.5 |
3/9 |
7.2 |
1.1 |
1440 |
3 |
380 |
50 |
0.4 |
1440 |
11/21 |
3 |
380 |
50 |
75-125 |
|
HHBB01-01 |
1 |
3/9 |
6.8 |
1.5 |
1440 |
3 |
380 |
50 |
0.4 |
1440 |
11/21 |
3 |
380 |
50 |
68-153 |
|
HHBB01-02 |
1 |
3/9 |
3.6 |
1.1 |
1440 |
3 |
380 |
50 |
0.4 |
1440 |
11/21 |
3 |
380 |
50 |
68-153 |
|
HHBB1.5-01 |
1.5 |
3/9 |
8.8 |
3.0 |
1440 |
3 |
380 |
50 |
0.4 |
1440 |
11/21 |
3 |
380 |
50 |
82-178 |
|
HHBB02-01 |
2 |
3/9 |
6.6 |
3.0 |
1440 |
3 |
380 |
50 |
0.4 |
1440 |
11/21 |
3 |
380 |
50 |
82-178 |
|
HHBB02-02 |
2 |
3/9 |
3.4 |
1.5 |
1440 |
3 |
380 |
50 |
0.4 |
1440 |
11/21 |
3 |
380 |
50 |
82-178 |
|
HHBB2.5-01 |
2.5 |
3/9 |
5.4 |
3.0 |
1440 |
3 |
380 |
50 |
0.75 |
1440 |
11/21 |
3 |
380 |
50 |
|
|
HHBB03-01 |
3 |
3/9 |
5.4 |
3.0 |
1440 |
3 |
380 |
50 |
0.75 |
1440 |
11/21 |
3 |
380 |
50 |
100-178 |
|
HHBB03-02 |
3 |
3/9 |
4.4 |
3.0 |
1440 |
3 |
380 |
50 |
0.75 |
1440 |
11/21 |
3 |
380 |
50 |
100-178 |
|
HHBB03-03 |
3 |
3/9 |
2.2 |
1.5 |
1440 |
3 |
380 |
50 |
0.75 |
1440 |
11/21 |
3 |
380 |
50 |
100-178 |
|
HHBB05-02 |
5 |
3/9 |
2.7 |
3.0 |
1440 |
3 |
380 |
50 |
0.75 |
1440 |
11/21 |
3 |
380 |
50 |
112-178 |
|
HHBB7.5-03 |
7.5 |
3/9 |
1.8 |
3.0 |
1440 |
3 |
380 |
50 |
0.75 |
1440 |
11/21 |
3 |
380 |
50 |
112-178 |
SY HHBB Series Electric Chain Hoist(Low Headroom Type) Parameter
|
Model |
Capacity (Ton) |
Lifting Height (m) |
Lifting Speed (m/min) |
Lifting motor |
Operating motor |
||||||||||
|
Power (KW) |
Rotation Speed (R/min) |
Phases |
Voltage (V) |
Frequency (Hz) |
Power (KW) |
Rotation Speed (R/min) |
Operating speed(m/min) |
Phases |
Voltage (V) |
Frequency (Hz) |
I-Beam(mm) |
||||
|
HHBB0.5-01L |
0.5 |
3/9 |
7.2 |
1.1 |
1440 |
3 |
380 |
50 |
0.4 |
1440 |
11/21 |
3 |
380 |
50 |
|
|
HHBB01-01L |
1 |
3/9 |
6.8 |
1.5 |
1440 |
3 |
380 |
50 |
0.4 |
1440 |
11/21 |
3 |
380 |
50 |
82-153 |
|
HHBB01-02L |
1 |
3/9 |
3.6 |
1.1 |
1440 |
3 |
380 |
50 |
0.4 |
1440 |
11/21 |
3 |
380 |
50 |
82-153 |
|
HHBB1.5-01L |
1.5 |
3/9 |
8.8 |
3.0 |
1440 |
3 |
380 |
50 |
0.4 |
1440 |
11/21 |
3 |
380 |
50 |
100-178 |
|
HHBB02-01L |
2 |
3/9 |
6.6 |
3.0 |
1440 |
3 |
380 |
50 |
0.4 |
1440 |
11/21 |
3 |
380 |
50 |
100-178 |
|
HHBB02-02L |
2 |
3/9 |
3.4 |
1.5 |
1440 |
3 |
380 |
50 |
0.4 |
1440 |
11/21 |
3 |
380 |
50 |
100-178 |
|
HHBB2.5-01L |
2.5 |
3/9 |
5.4 |
3.0 |
1440 |
3 |
380 |
50 |
0.75 |
1440 |
11/21 |
3 |
380 |
50 |
100-178 |
|
HHBB03-01L |
3 |
3/9 |
5.4 |
3.0 |
1440 |
3 |
380 |
50 |
0.75 |
1440 |
11/21 |
3 |
380 |
50 |
100-178 |
|
HHBB03-02L |
3 |
3/9 |
4.4 |
3.0 |
1440 |
3 |
380 |
50 |
0.75 |
1440 |
11/21 |
3 |
380 |
50 |
100-178 |
|
HHBB05-02L |
5 |
3/9 |
2.7 |
3.0 |
1440 |
3 |
380 |
50 |
0.75 |
1440 |
11/21 |
3 |
380 |
50 |
112-178 |
|
HHBB7.5-03L |
7.5 |
1.8 |
2*3.0 |
1440 |
3 |
380 |
50 |
0.75 |
1440 |
11/21 |
3 |
380 |
50 |
112-178 |
|
|
HHBB10-04L |
10 |
3/9 |
2.7 |
2*3.0 |
1440 |
3 |
380 |
50 |
0.75 |
1440 |
11/21 |
3 |
380 |
50 |
150-220 |
NOTE
1. The installation position of the electric chain hoist must be selected in the occasion that meets the needs.
2. Regularly check whether the installation of the electric chain hoist is firm.
3. Please do not overload or use an electric chain hoist when you are not sure about the weight of the lifting goods.
4. It is strictly forbidden for anyone to stand under the lifting weight when lifting the heavy weight with the electric chain
hoist. 5. Please do not modify the parts of the electric chain hoist at will.
6. When operating the chain, please wear thick gloves to avoid slipping or puncture.
